Variable carriage widths and lengths
Flat drylin® guide rails or high profile
Corrosion resistant option made of stainless steel available
Format and lane adjustments
Packaging technology
Height adjustments
3D printers
Camera adjustment
Shaft end supports made from anodised aluminium or from chromated die-cast zinc
Lead screw mounted with plain or ball bearings
Mounting plates made from anodised aluminium
Lead screw material: steel or stainless steel
Drive: self-locking trapezoidal thread or quick adjust high helix thread
Flat and compact
High torsional stability
Fully supported
Hard-anodised aluminium rail
Flat and compact
High torsional stability
Fully supported
Hard-anodised aluminium rail
Lower drive force
Minimised clearance up to 1,500 RPM (according to length and load)
Quiet operation - reduced vibration of the overall system
Pitch 8 x 15 mm
Flat and compact
High torsional stability
Hard-anodised aluminium rail
Trapezoidal or high helix threads
Ball bearing leadscrew supports
Rail profile in higher design, extremely torsion-resistant
Stainless steel version with corrosion-resistant steel components (1.42305, 1.4408 or 1.4571)
Choose your bearing material
drylin® W profile rail as a protective mechanism
Available with pitches 10x2, 10x12,10x50
Low profile design
3 carriage lengths
Different lead screw pitches can be combined
Separate manual adjustment of carriages
Lubrication-free drylin® W linear guide
Clearance adjustment (optional)
Single parts made from aluminium and plastic
Lubrication-free
Entry-level model
Lead screw mounted with plain bearings
Retrofitting possible
Small and compact
Based on lubrication-free drylin® N low profile guides installation size 27
100 % lubrication-free
Lead screw, ball bearing mounted for anti-backlash and dynamic operation
Manual and motorised operation possible
SLN-27: linear axis with NEMA11 stepper motor, lead screw ball bearing mounted via motor mount, or ball bearing mounted linear axis with NEMA11 stepper motor
Small (installation dimensions from 22 mm), light and flat
Polymer plain bearings in the bearing points
Low profile structure through lateral lead screw arrangement
Lubrication-free, corrosion-resistant, lightweight
Variable pitch
Adjustable drylin® T miniature carriage
Lead screw arrangement can be selected either left or right
Sensor integrated in the carriage, saving space
Operation without mains supply
Integrated magnetic tape
Lubrication-free operation
Extensive accessories available
Low-cost- XY-table solution for manual adjustments
Lubrication-free and corrosion-resistant
Maximum stroke lengths for XY-tables 300 mm
For manual adjustments
Flat and compact
Entire structure made from VA and V4A stainless steel materials
Chemical and corrosion resistant
For your stepper motor
type NEMA-23
Lead screw drive mounted with ball bearings
Pitches 2 mm, 3 mm, 12 mm or 50 mm per revolution
Compact design, light weight, stable.
